Logitech Group Product Support

Is the PTZ Pro 2 remote compatible with Group?

Yes, the PTZ Pro 2 remote controller is compatible with the Logitech Group system. This means you can use the PTZ Pro 2 remote to control the camera in the Logitech Group setup, offering similar functionality for pan, tilt, and zoom operations.

Can I use GROUP with a tablet?

Yes, most tablets equipped with USB and Bluetooth functionalities should recognize GROUP with a few limitations: If your tablet is USB-enabled (comes with a USB port), you can utilize the full functionality of video and audio. If your tablet isn’t USB enabled, you can utilize only audio functionality through Bluetooth.

Does GROUP work with WebRTC solutions (Chrome, Firefox, etc)?

GROUP is compatible with standard WebRTC, although different builds may have different requirements that should be evaluated.

How wide is the Group lens angle?

GROUP has a 90° field of view.

What kind of batteries does the Group remote need?

GROUP’s remote uses two CR2032 batteries.

Does GROUP support wide screen?

Yes, the default aspect ratio is 16:9, but GROUP can support other aspect ratios as well.

Can GROUP be powered by USB alone?

The motors and circuitry draw more power than can be supplied from USB and therefore a separate power supply is needed and included.

Purchasing Business Product Spare Parts and Accessories

To purchase spares, please visit Logitech Spare Parts and Accessories. You can purchase accessories directly from Logitech or from a local reseller. Note: Availability of spare parts may vary by country. Please check with your reseller or place of purchase if you are not able to purchase spares from us directly.

GROUP Specifications

Product Information Component Model Number (M/N) / Serial Number (S/N) Location: Camera: V-U0032 / Under camera Hub: V-U0033 / N/A Speakerphone: V-U0036 / Under speakerphone Remote Control: R-R0007 / N/A Expansion Microphone*: V-U0037 / Under microphone Product Dimensions Camera: Height: 170 mm (7 inches) Width: 130 mm (5.1 inches) Depth: 138 mm (5.4 inches) Weight: 585 g (21 ounces) Hub: Height: 34 mm (1.3 inches) Width: 94 mm (3.75 inches) Depth: 74 mm (2.9 inches) Weight: 83 g (3 ounces) Speakerphone: Height: 65 mm (2.5 inches) Width: 240 mm (9.5 inches) Depth: 240 mm (9.5 inches) Weight: 1223 g (43 ounces) Remote Control: Height: 12 mm (.5 inches) Width: 50 mm (2 inches) Depth: 120 mm (5 inches) Weight: 51 g (2 ounces) Expansion Microphone: Height: 21 mm (1.3 inches) Width: 83 mm (3.3 inches) Depth: 83 mm (3.3 inches) Weight: 230 g (8 ounces) General Product Specifications OS/Platform Support: Windows 8, Windows 8.1, Windows 10, Windows 11 Mac OS X 10.7 or later Google Chromebook Version 29 or higher System Requirements: CPU Minimum: Intel Core 2 Duo 2.4 GHz or better RAM Minimum: 2 GB USB 2.0 port Certified Client Applications: Certified for Skype® for Business and Microsoft® Teams Cisco Jabber Cisco WebEx Microsoft Lync 2013 Compatible Applications: Applications that support USB audio and video devices Camera Specifications Connection Type: Output: Mini-DIN 6-pin (to Hub) USB VID_PID: 046D_0858 USB Protocol: USB 2.0 USB Speed: High-speed Lens Type: Premium Logitech Camera Glass Lens Focus Type: Auto Zoom: Yes; 10x HD zoom (5x optical, 2x digital) Optical Resolution: 3MP (up to 1080p) Field of View (FOV): Diagonal: 90° (Wide); 22° (Tele) Horizontal: 82.1° Vertical: 52.2° Pan: ±90° Tilt: +35° / -45° Focal Length: 10 cm to infinity (Wide) 80 cm to infinity (Tele) Frame Rate (Max): 30 fps UVC Support: Yes; UVC 1.5 Video Encoding: H.264 (via hardware) RightLight™: RightLight™ 2 Indicator Lights (LED): Color: Blue - call status Mountable: Yes (table/wall mount included) Tripod Mounting Option: Standard, 1/4-20 UNC Cable Length: 5 m (16 ft) [to Hub] Security: Kensington Lock Slot Hub Specifications Connection Type: Output: USB Type mini B to Type A (to host), Input: (2x) Mini-DIN 6-pin (from camera and speakerphone) USB VID_PID: 046D_085A USB Protocol: USB 2.0 USB Speed: High-speed Indicator Lights: LED Color: Blue (call status) Cable Length (Power): 3 m (9.8 ft) Cable Length (USB): 2 m (6.6 ft) Power Adapter: Yes Speakerphone Specifications Connection Type: Output: Mini-DIN 6-pin (to Hub), Input: (2x) D-Sub connector (from satellite microphones) USB VID_PID: 046D_0857 USB Protocol: USB 2.0 USB Speed: Full-speed Wireless Protocol: Bluetooth 4.0, NFC (for auto pairing with NFC-enabled devices) Wireless Range: 10m (33 ft) Bluetooth Profiles: HFP (version 1.6) A2DP (version 1.2) AVRCP (version 1.4) NFC: Yes Speaker Type: Built-in (1); Mono Speaker Driver Dimensions: 51 mm (2.01 inches) x 51 mm (2.01 inches) x 31.8 mm (1.25 inches) Speaker Frequency Response: 120 Hz - 14 kHz Speaker Sensitivity: 83dBSPL Maximum Speaker Output: 91dBSPL Speaker Impedance: 4 Ohm Microphone Type: Built-in (4); Omni-directional (with beamforming technology) Noise Canceling: Yes Microphone Frequency Response: 100 Hz - 11 kHz Microphone Sensitivity: -28dB Input/Output Range (Diameter): 20 ft (28ft with expansion microphones) Display: TFT 2.4 in. LCD Buttons/Controls: Bluetooth pairing Call answer Call end Camera presets (3) Camera pan/tilt (4) Camera zoom in Camera zoom out Far end camera control Microphone mute Speaker volume up Speaker volume down Indicator Lights (LED): Color: Blue - active call (solid); call on hold (flashing); Bluetooth device pairing (flashing) Color: Red - microphone mute (solid) Cable Length: 5 m (16 ft) [to Hub] Security: Kensington Lock Slot Remote Control Specifications Remote Type: Infrared (IR) Battery Type: Removable; Replaceable Battery Details: Size: CR2032 (3V) Coin cell Quantity: 1 Type: Lithium Buttons/Controls: Call answer Call end Camera presets (5) Camera pan/tilt (4) Camera zoom in Camera zoom out Far end camera control Microphone mute Speaker volume up Speaker volume down Expansion Microphone Specifications Connection Type: D-Sub connector (to speakerphone) Microphone Type: Built in (1); Omni-directional (per microphone) Noise Canceling: Yes Microphone Frequency Response: 100 hz - 20 kHz Microphone Sensitivity: -24dB Buttons/Controls: Microphone mute Indicator Lights (LED): Color: Blue - active call Color: Red - microphone mute Cable Length: 2.4 m (8 ft) GROUP Expansion Microphones (add-on bundle) Part Number 989-000171 Dimensions Height: 3.27 in (83 mm) Width: 3.27 in (83 mm) Depth: 0.83 in (21 mm) Weight: 8.11 oz (230 g) Technical Specifications Connection Type: Plug-and-play Indicator Lights (LED): LED to confirm video streaming, microphone mute, on-hold, and Bluetooth pairing. Microphone Type: Mono, wideband, noise canceling Buttons / Switch: Microphone mute Warranty Information 2-Year Limited Hardware Warranty In the Box Two expansion microphones

GROUP Compatibility Information

GROUP Operating Systems Compatibility GROUP is natively supported on the operating systems listed below through the UVC standard and does not need additional software. Operating Systems supported for GROUP are: Windows 8.1 and Windows 10 or higher. macOS 10.10 or higher. ChromeOS Version 29.0.1547.70 or higher. Please note that factors such as CPU speed and memory usage on your computer can impact video and audio performance. Video Conference Software Compatibility GROUP is designed to work across any video conferencing software -- including those listed above, or just about any conferencing software that will run on a USB-enabled computing system (Windows, Mac or Chrome). Logitech partners with many vendors to provide you a wide selection of the software and hardware you prefer to work with. You can use GROUP with most Video Conference (VC) applications including: Zoom Microsoft Teams Google Meet
