Foldable, ultra-portable mouse for wherever business takes you
Mouse
Mobi Fold
How to replace the Mobi Fold for Business Battery
1. Open the battery compartment using the finger recess on the battery cover. 2. Loosen the screw that holds the battery securely in place before taking out the battery. 3. Follow your local regulations and guidelines to dispose of the used battery at a designated collection point or recycling facility in your area. 4. To order a replacement battery, please visit iFixit. Specifications - Mobi Fold for Business
Category Technical Details Product Details Mouse • Model Number (M/N): MR0121 • Location: Laser etched on the bottom case inside the battery compartment. Receiver • Model Number (M/N): CU0028 • Location: Side of the product Compliance Certificates CE/CCC/EAC/FCC, Battery MSDS, HS Codes: Logitech Compliance Product Dimensions Mouse • Height in open mode: 4.8 in (122 mm) • Height in close mode: 2.6 in (66 mm) • Width in open & close mode: 2.2 in (57 mm) • Depth in open mode: 1.3 in (33 mm) • Depth in close mode: 0.8 in (21 mm) • Weight: 2.79 oz (79 g) Logi Bolt USB-C receiver • Height: 0.28 in (7 mm) • Width: 0.51 in (12.85 mm) • Depth: 0.56 in (14.1 mm) • Weight: 0.03 oz (0.97 g) General Product Specifications System Requirements USB-C port or Bluetooth® Low Energy OS/Platform Support- Logi Bolt USB-C Receiver • Windows 10, 11, or later • macOS 12 or later • ChromeOS* • Linux* Note: *Device basic functions will be supported without software for other systems than Windows and macOS. OS/Platform Support - Bluetooth® Low Energy (BLE) • Windows 10, 11, or later • macOS 12 or later • ChromeOS* • Linux* • Android 12 or later* • iPadOS 15 or later* Note: *Device basic functions will be supported without software for other systems than Windows and macOS. Device Management Apps Logi Tune, Logitech Sync Mouse Specifications Connection Type(s) Logi Bolt USB-C + Bluetooth Low Energy Direct (3 channels) USB Architecture • USB Protocol: N/A • USB Speed: N/A • USB Data Format: N/A • USB Report Rate: N/A Wireless Performance • Bolt Report Rate: 11.25 ms • Bluetooth Report Rate: 11.25 ms Microprocessor nRF52820 DPI (Min/Max) 400 - 4000 DPI (in increments of 100 DPI) Sensor PAW3222 Indicator Lights (LED) • TOP: (1) battery indicator • BOTTOM: (1) connectivity Buttons 4 buttons (Left/Right click, Forward/Back under touchscroll) + Connectivity button Durability (button presses) • Buttons (Left / Right): 5M clicks • Buttons (Forward and Backward): 1M clicks • Connectivity button (host button): 10K clicks Durability feet (Material type + KM Range): POM Feet: 250 km range Materials used • PCR Plastic: Graphite 36% • Silicone rubber: CHN-9500-U MT11006 Other Features • Adaptive touch scrolling • Quiet clicks Battery Details Rechargeable Li-Po (100 mAh) Battery Life (rechargeable) • Up to 1 month on full charge* • 1-min quick charge powers up to 22 hours* Note: *Battery life may vary based on user and computing conditions. Is the battery user replaceable? Yes Corded or Wireless Wireless Wireless range 10m / 33ft Mobi Fold For Business Quick Start Guide
Mobi Fold For Business features a Japan-specific quick start guide, as well as a multilingual guide covering the rest of the world. Multilingual Japanese How to Clean Your Logitech Device
We recommend that you clean your Logitech device on a regular basis, either daily, weekly or monthly, especially if you have a light colored device. In the event your Logitech device needs deep cleaning we have some recommendations: Warning! Don’t use bleach, acetone/nail polish remover, strong solvents or abrasive cleaning products. We don't recommend using any of these, although strong solvents or abrasives, such as degreasers, may help remove tough stains. Please consult the cleaning product instructions and guidelines before use, as damage can occur to your Logitech product if used incorrectly. If you do choose to use bleach, acetone/nail polish remover, strong solvents, or abrasives Logitech is not liable for any damage that may occur and any damage would be considered out of warranty. Before You Clean If your device is cabled, please unplug your device from your computer first. If your device has user-replaceable batteries, please remove the batteries. Be sure to switch off your device and then wait 5-10 seconds before starting to clean. Don’t put cleaning liquids directly on your device. For devices that are not waterproof, please keep moisture to a minimum and avoid any liquid dripping or seeping into the device When using cleaning sprays, spray the cloth and wipe — do not spray the device directly. Never submerge the device in a liquid, cleaning or otherwise. Cleaning Keyboards To clean the keys, use regular tap water to lightly moisten a soft, lint-free cloth and gently wipe down the keys. Use compressed air to remove any loose debris and dust between the keys. If you do not have compressed air available, you could also use cold-air from a hair-dryer. You can also use fragrance-free disinfecting wipes, fragrance-free anti-bacterial wet wipes, makeup removing tissue, or alcohol swabs containing less than 25% concentration of alcohol. Cleaning Mice or Presentation Devices Use tap water to lightly moisten a soft, lint-free cloth and gently wipe down the device. Use lens cleaner to lightly moisten a soft, lint-free cloth and gently wipe down your device. You can also use fragrance-free disinfecting wipes, fragrance-free anti-bacterial wet wipes, makeup removing tissue, or alcohol swabs containing less than 25% concentration of alcohol. Cleaning Webcams Use tap water to lightly moisten a soft, lint-free cloth and gently wipe down the device. Use lens cleaner to lightly moisten a soft, lint-free cloth and gently wipe down the webcam lens. Battery Replacement Information
Logitech has partnered with iFixit to provide users with convenient resources for battery replacement. Through the Logitech Repair Hub hosted by iFixit, users can access detailed instructions for battery replacement, and purchase replacement batteries directly from the platform. Supported devices The following Logitech products for business feature a replaceable battery for product longevity: Category Product Part Number Headsets Zone Wireless 2 533-000214 Zone Wireless 2 ES for Business 533-000214 Zone 305 533-000201 Mice MX Master 4 for Business 533-R00250 MX Master 3S for Business 533-000205 MX Anywhere 3S for Business 533-000205 Mobi Fold for Business 533-R00249 (Coming soon) Keyboards Signature Slim Solar+ K980 for Business 533-000248 Supported countries Replaceable batteries are available in 34 countries, covered by 6 iFixit Online Repair Hubs: Online Store Supported Countries (Logistically) iFixit Europe Austria, Belgium, Bulgaria, Croatia, Czech Republic, Denmark, Estonia, Finland (including Åland), Greece, Ireland, Italy, Latvia, Lithuania, Luxembourg, Netherlands (mainland), Norway, Poland, Portugal (mainland), Romania, Slovak Republic, Slovenia, Spain (Mainland), Sweden, and Hungary Iceland iFixit UK United Kingdom iFixit Germany Germany, Switzerland iFixit France France iFixit Canada Canada iFixit Australia Australia, New Zealand iFixit USA United States
